Semi Automatic Shrink Wrapping Machine

Product Category

Semi Automatic Shrink Wrapping Machine

Semi Automatic Shrink Wrapping Machine

Unitech Water Solution is an Exporter & Manufacturer of Pet Bottle Shrink Wrapping Machine.

Request A Quote
Bottle group Semi Automatic Sealing machine

Put bottles in front table of sealing machine Press pusher button, bottle will be pushed and Shrink roll will be wrapped on bottle. After the same, film will seal & cut. Again go for second bottle grouping & pushing

The bottle group will be delivered in to the shrink tunnel

Shrink Wrapping Tunnel

Bottle group shrink wrapping machine: The S. S. conveyor chain will rotate & take the bottle packet to shrink tunnel, after shrinking in tunnel, the pack will be coming outside and the fan will cool off the duly shrink wrapped bottle group.

Technical Specification
Sr.No. Particular Specifications
SHRINK TUNNEL
1 Tunnel Dimensions* 1200 mm x 560 mm x 460 mm
2 Max. Packing Size 550 mm x 450 mm
3 Power Supply 415 V x 3 PH x 50 Hz
4 Connected Load 11 KW
5 Control PID/Timer Control
6 Conveyor SS Mesh Conveyor
7 Conveyor Speed 0 - 10 m/min (Variable)
8 Packing Speed 4 - 5 Packs/minute
9 Material of Construction (Outer / Inner) MS Powder Coated & Contact Parts SS 304
10 Film Material POF / PVC / LDPE
11 Length of Tunnel 9 Feet
WEB SEALER
1 Maximum Packing Size 750 mm x 500 mm x 450 mm
2 Max. Sealing Length* 800 mm
3 Power Requirement 220 V x 1 PH x 50 Hz
4 Connected Load 1 KW
5 Working height of machine 750 mm +/- 50 mm
6 Max. Pack Height 350 mm
7 Air Requirement 4 CFM @ 6 bar
8 Length of Web Sealer 4 - 5 Feet
9 Total Machine Weight 500 Kg
